Panasonic EP-MA70

EP-MA70
ORDER NO. HPD1102U24CE
- 76 -
11. REPLACEMENT PARTS LIST
Ref.No. Part No. Part Name & Description Remarks
Per
Unit
1 WEPMA70L0087 REAR FRAME 1
2 WEP3530L0007 SIDE HINGE FITTING RIGHT 1
3 WEP3530L0017 SIDE HINGE FITTING LEFT 1
4 WEP3530L6717 SCREW 20
5 WEP3200L0887 RESIN BUSHING 12
6 WEPMA70L0267 REAR COVER FIXING PLATE 1
7 WEP2000L9567 SCREW 55
8 WEP2005L0687 WIRE ON CHAIR 1
9 WEPMA50L0767 RAIL PIECE RIGHT 1
10 WEPMA50L0777 RAIL PIECE LEFT 1
11 WEP573L6627 SCREW 16
12 WEPMA70L3787 SHOULDER SIDE PLATE SMALL 2
13 WEPMA70L3797 SHOULDER SIDE PLATE LARGE 2
14 WEPMA70L0907 REAR FRAME FULCRUM PIN 2
15 WEP3010L0417 OTTOMAN LIFT PIN LONG 4
16 WEP596N0357 SNAP PIN 8
17 WEPMS40K3907 CASTOR 2
18 WEPMS40L0917 HINGE PIN A MO 2
19 WEPMA70K0097 UNDER PIPE 1
20 WEPMA70L0497 S-SHAPED SPRING
1
21 WEPMA70L1538 RECLINING LIFT UNIT 1
22 WEPMA70L1528 OTTOMAN LIFT UNIT 1
23 WEP578K3377 BOTTOM COVER 5
24 WEP3510S9027 SCREW 35
24 WEP3510S9017 SCREW 12
25 WEPMA70L0057 ARMREST FIXING BRACKET 2
26 WEPMA70K3807 UNDER CLOTH 1
27 WEP596K0457 PUSH-TURN RIVET 15
28 WEP3510L9687 SCREW 1
29 WEP005W8517 CABLE TIE MEDIUM 3
30 WEP005W8527 CABLE TIE LARGE 1
31 WEPMA70K2018 POWER SOURCE SWITCH BLOCK 1
32 WEP1260L2938 POWER CORD 1
33 WEPMA70L2868 CONNECTING CORD FOR POWER SOURCE A 1
34 WEPMA70L0077 POWER SOURCE SWITCH BOX INSTALL PLATE 1
35 WEPMS40L7868 KEY 1
36 WEPMA70K1577 LOCK RELEASE LEVER HEAD K 1
36 WEPMA70C1577 LOCK RELEASE LEVER HEAD C 1
37 WEPMA70L1567 LOCK RELEASE LEVER B 1
38 WEPMA70L9647 SCREW 1
39 WEPMA70L1587 LOCK RELEASE LEVER A 1
40 WEPMA70L1197 LOCK SPRING 1
41 WEPMA70L0877 LEVER PIVOT 2
42 WEP2110L9588 SCREW 2
43 WEP3200L9667 SCREW 1
