Parts identification
Nozzle
Body handle
Air inlet
(right side)
Power cord
storage
Power cord
Power plug
Filter (small)
Control panel
Alert indicator
Check the product when it lights up. (P.28
7
,
8
)
Timer indicator
As time elapses, the indicator shows the
approximate remaining time.
Control panel
Front Back
Nozzle handle
Air outlet
Louver
Air inlet (left side)
Filter cover (large) Filter cover (small) Cover
Filter (large)
Hose
(Extend up to approximately 55 cm)
Summer
button
Operation indicator
(Summer)
Winter
button
Stop button
Alert
indicator
Operation indicator
(Winter)
When drying futon
in winter (P.24)
When taking anti-mite
measures (P.25)
When warming
futon (P.24)
Fan operation gets rid of the
heat after drying futon. (P.24)
When drying futon
in summer (P.24)
When drying
clothes (P.26)
Timer indicator
