FP0 – Impressive Capabilities
High specifications for both speed and capacity
0.9µs per basic instruction. Pulse catch and interrupt input functions meet the need for high-speed response.
High-speed execution
Execution speed of 0.9µs per basic instruction. 500 steps program yields a scanning time of 1ms, which means the FP0
boosts the fastest processing time among the products of this class.
• Internal processing in the FP0
Large capacity
Pulse catch function
Can read pulses as short as 50µs, which greatly facilitates
sensor input.
• Pulse catch function
Interrupt input function
Accurate processing, unaffected by scan time
• Interrupt input function
I/O
refresh
Program
execution
I/O
refresh
Program
execution
1 scan
I/O
refresh
Program
execution
Internal processing in the FP0
I/O
refresh
Program
execution
I/O
refresh
Program
execution
Sensor input
signal
Cannot
read.
Lengthening
of sensor
input signal
Can
read!
With pulse catch function
Internal processing in the FP0
I/O
refresh
Program
execution
I/O
refresh
Program
execution
Interrupt
program
Interrupt input
Interrupt program executed when
interrupt input enters.
A top-class large 5k and 10k steps program capacity housed within a compact body. Furthermore, data capacity for internal
devices like the data register is also ample. The unit's high performance is even suited to complicated controls
and controls with multiple amounts of data.
I/O 10-point, 14-point, 16-point type
Control unit type
I/O 32-point type
2 720 steps
1 660 words
5 000 steps
6 144 words
1 008 points
144 points
FP0-T32 CP/T
10 000 steps
16 383 words
Program size
Internal relays
Timers/Counters
Data registers
FP0_broschüre_4093 euen0904 15.10.2004 8:42 Uhr Seite 6
