FP2−CCUTable of Contents
ii
Chapter 4 RS232C Port Wiring
4.1 RS232C Port Signals 4 − 3..............................................
4.2 Wiring between RS232C Ports 4 − 5......................................
4.2.1 Connecting to a Personal Computer 4 − 5.........................
4.2.2 Connections with Operation Display Panel 4 − 6....................
4.2.3 Connections with RS232C Devices 4 − 7..........................
4.2.4 Modem Connections 4 − 8.......................................
Chapter 5 Troubleshooting
5.1 Operation if an Error Occurs 5 − 3........................................
5.1.1 If the ALARM LED on the Computer Communication Unit
Lights 5 − 3....................................................
5.1.2 If the ERROR LED on the Computer Communication Unit
Lights 5 − 4....................................................
5.2 What to Do if an Error Occurs 5 − 5.......................................
5.2.1 If the ALARM LED on the Computer Communication Unit
Lights 5 − 5....................................................
5.2.2 If the ERROR LED on the Computer Communication Unit
Lights 5 − 5....................................................
5.2.3 Communication is Inhibited 5 − 6.................................
5.2.4 If an Error Response is Returned to the Host Side 5 − 6.............
Chapter 6 Specifications
6.1 Specifications 6 − 3.....................................................
6.2 Table of MEWTOCOL Command 6 − 4....................................
6.2.1 MEWTOCOL−COM Commands 6 − 4.............................
6.3 Table of MEWTOCOL−COM Error Code 6 − 5..............................
Record of changes R − 1..............................................
