FP2−CCUInterchangeability with the FP3 and Precautions
iv
Comparison of specifications between the FP2 and FP3 Computer
Communication Units
Setting item Set value FP2 FP3
No. of ports — 2 ports 1 port
Transmission speed (Baud rate) 19,200 bits/s
φ φ
9,600 bits/s
φ φ
4,800 bits/s
φ φ
2,400 bits/s —
φ
1,200 bits/s —
φ
600 bits/s —
φ
300 bits/s —
φ
Transmission speed (Baud rate)
9,600 bits/s
φ
—
when modem is connected
2,400 bits/s —
φ
Character bit 7−bit
φ φ
8−bit
φ φ
Parity None —
φ
Odd
φ φ
Even —
φ
Stop bit 1−bit
φ φ
2−bit —
φ
Control signals CS and CD Invalid
φ φ
Valid —
φ
Reset switch — None Provided
φ : Default setting, or can be set using DIP switches
—: Cannot be set
