Panasonic FV-23BW2H - Supplied Accessories

6
In extreme weather condition(rainfall precipitation more than 240 mm/h. wind
speed higher than No.8 typhoon.), there may be water through frame into
bathroom.
When you install plastic part, do not exert too much strength to fixing the screw
.
(the recommended screw fixing torque is 0.78 N m), otherwise, the product would
be damaged.
Do not install this product in a public bath room.
Do not install this product in a wardrobes.
請勿把本產品安裝在公 共 浴室。
請勿把本產品安裝在衣 櫃 內。
在極端惡劣的天氣條件 下(雨 量大於240 mm/h，風速大於8號風球)，可 能 會有水通過產品框架
進入浴室內部。
.
安裝塑料部件時，為了 不 損壞產品，鎖螺絲時請 注 意不要用力過大(建議鎖緊 扭 矩為0.78 N m)。
包裝附件清單
Product warranty registration
產品保 修登記
Do not cover air outlet, maybe it can cause breakdown.
請勿覆蓋產品出風口，否 則可能會引起機體故障。
安裝要求
INSTALLATION REQUIREMENTS
SUPPLIED ACCESSORIES
Installationandoperatinginstructions
Louver assembly
Remote control panel Chinese card
No.
Drawing
Nameandpurpose
Machinescrew(M4×10,usedtoinstallthelouver assembly)
1
1
1
1
1
1
2
4
Self-tappingscrew( 4×16,usedtoinstallthecontroller
holder) (placed on the backside of controller holder)
Self-tappingscrew( 4×25,usedtoinstallthe
mainbodyandthewindow)
Qty
面板組 合
名稱及 用途
安裝使 用說明書
機械螺 絲(M4×10用 於面板組 合安裝)
自攻螺 絲( 4×25用於機體 與窗體的安 裝)
圖樣
代號
數量
自攻螺 絲( 4×16用於遙控 器底座安裝) (放置於遙控器底座背 面)
遙控面 板中文卡
Remote control (included CR2032 battery)
遙控器(內 附CR2032電池)
