What to do if Panasonic GT05 Monitor screen is blank?
If your Panasonic Monitor screen is blank, there are a couple of potential causes. First, ensure that the power supply is connected to the unit according to the specifications. Second, if only lamp and message parts are configured to the base screen, verify that the address of the substitute reference device and the device values on the PLC side are correct.
What to do if Panasonic GT05 Monitor displays [Screen No. Error]?
If your Panasonic Monitor displays '[Screen No. Error]', it could be due to several reasons. * The screen settings from the PLC, the GT’s switch part or the auto-paging indicate an unregistered screen number. If this is the case, create and register screen content or specify the correct screen number. * When bringing up the keyboard screen during data input, an unregistered keyboard screen number was specified. In this case, create and register keyboard screen or specify the correct keyboard number. * GT configuration data and keyboard screen data exist in the GT, but there is no base screen data. To solve this, transfer base screen data from GTWIN.
What to do if Panasonic GT05 displays [Memory is Full]?
If your Panasonic Monitor displays '[Memory is Full]', it means that the total capacity of transferred base screen data exceeds the 384 Kbyte capacity of the GT. To resolve this, delete part of the base screen data so that the capacity doesn’t exceed the total capacity. You can check data capacity by going to [View (V)]?[Memory Usage Conditions] on GTWIN menu bar. If the data capacity is not over the limit, invalid data could possibly be remaining in the GT; when transferring data, do so after deleting the screen.
Why does an unspecified screen appear or there is trouble when switching screens on Panasonic Monitor?
If an unspecified screen appears or you experience trouble when switching screens on your Panasonic Monitor, there are several potential reasons: 1. The screen specification in the PLC screen setting, the GT switch part or the auto-paging is wrong. To fix this, specify the correct screen number. 2. The startup screen is specified in the GT configuration settings (GTWIN). Check the start-up screen setting for the GT configuration settings in GTWIN. Delete unnecessary settings and re-transfer configuration data. 3. An erroneous device or value is specified in the first word of the basic communication area word device. Check the device content specified on the PLC side in the first word of the basic communication area. (Do not use the basic communication area with ladder programs.)
What does it mean if my Panasonic GT05 Monitor screen displays [No Screen data]?
If your Panasonic Monitor screen displays '[No Screen data]', it indicates that there is no base screen data in the GT. This appears even when GT configuration data exists. To resolve this, transfer base screen data.
Critical warnings about situations that could lead to death or serious injury from mishandling.
Warnings about situations that could lead to user injury or property damage from mishandling.
Describes the general capabilities and design aspects of the GT series.
Details the available GT series main units with their specifications.
Identifies and explains the various physical components and connectors on GT units.
Provides pin assignments and signal directions for COM port connections.
Covers environmental conditions, mounting, and installation procedures for GT units.
Details on how to properly connect the power supply to the GT unit.
Explains different methods for connecting GT units to PLCs.
Details RS232C connection procedures and terminal block differences.
Provides solutions for common problems encountered with specific GT models.
Lists and explains error codes displayed by the GT series and their resolutions.
Detailed specifications including general, performance, function, and interface for the GT01 model.
Specifications for GT32 models, including general, performance, function, and interface data.
Provides physical dimensions and panel cutout information for various GT models.
General| Resolution | 800 x 480 pixels |
|---|---|
| Type | TFT LCD |
| Backlight | LED |
| Touch Panel | Resistive |
| Brightness | 300 cd/m2 |
