6.9.3 Function Specifications (GT32)
Item
Specifications
GT32M
GT32T0/GT32T1
Displayable fonts
Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16)
(Double, quadruple or octuple in height and width)
True Type (GTWIN): 10 to 240 dots
Windows (R): 10 to 240 dots
Character types
English, Japanese, Korean, German, French, Italian, Spanish, Simplified
Chinese, Traditional Chinese characters, Turkish, Russian and Vietnamese can
be displayed.
Number of
registerable screens
Approx. 240 screens
Note1)
Approx. 180 screens
Note1)
Registerable screen
number
Base screen: No. 0 to 3FF
Keyboard screen: No. 0 to 7
Login screen: No. 0 to F
Graphics
Straight lines, continuous straight lines, squares, circles, ovals, arcs, elliptic
arcs, fan shapes, elliptic fan shapes, beveled squares
Types of parts
Switch
Function switch
Lamp
Message
Data
Bar graph
Clock
Note2) 3)
Line graph
Alarm list
Keyboard
Custom(message, lamp, switch)
Main functions
Note6)
Recipe
SD recipe
Flow display
Write device
Multi language exchange
Sound output
Note4)
Operation security
GT link
PLC multiple connection
Data logging
FP monitor
Through function
Connecting a computer to Ethernet port or USB port and our PLC to COM port
enables the communication between the PLC and the computer. (This function
is not available for PLCs manufactured by other companies.)
Note5)
Copy function
Screen data can be copied with a SD memory card.
GTWIN ver.
Ver. 2.80 or later
Note1) Maximum allowable number varies depending on registered contents.
Note2) External clock data can be referred and displayed.
Note3) Accuracy of the GT internal clock is ±180 seconds per month.
Note4) The sound output function is available for GT32T1 only.
Note5) An Ethernet port is available for GT32T1 only.
Note6) It depends on the version of GT.
