Panasonic GT05

9-2
9.1 EH-150/EHV Series
PLC model selection
Select "Hitachi EH/EHV series".
Usable devices
Bit/Word Device
No.
Memo
Bit Device
External input
X 00000~X 4FF95
External output
Y 00000~Y 4FF95
Internal output
R 000~R FFF
Internal output
WR 0000.0~WR FFFF.F
*
CPU link
L 00000~L 73FFF
Internal output
WN 00000.0~WN 1FFFF.F
*
Data area
M 00000~M 7FFFF
Extended external input
EX 00000~EX 5A7FF
Extended external output
EY 00000~EY 5A7FF
On delay timer
TD 0000~TD 2559
Off delay timer
TDN 0000~TDN 2559
Single shot
SS 0000~SS 2559
Monostable timer
MS 0000~MS 2559
Integrating timer
TMR 0000~TMR 2559
Watchdog timer
WDT 0000~WTD 2559
Counter
CU 0000~CU 2047
Ring counter
RCU 00000~RCU 2047
Updown counter
CT 00000~CT 2047
Word Device
External input
WX 0000~WX 4FF5
External output
WY 0000~WY 4FF5
Internal output
WR 0000~WR FFFF
CPU link
WL 0000~WL 73FF
Internal output
WN 00000~WN 1FFFF
Data area
WM 0000~WM 7FFF
Extended external input
WEX 0000~WEX 5A7F
Extended external output
WEY 0000~WEY 5A7F
Timer/Counter current value
TC 0000~TC 2559
* The input in GTWIN is as follows:
Note:
- The maximum value that can be set with the GT is described.
- The range of usable addresses differs depending on the model. For details, please consult the manual
for the PLC you will use.
