HDC-HS700 vol.1
Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
R3908 ERJ2GEJ103 M.RESISTOR CH 1/10W 10K 1
■ VEP03H98AN MAIN PCB UNIT 1 P,PC,PU,GT (RTL) E.S.D. R3909 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1
■ VEP03H98AQ MAIN PCB UNIT 1 EE,GC,GN (RTL) E.S.D. R3910 ERJ2GEJ271 M.RESISTOR CH 1/10W 270 1
■ VEP03H98AP MAIN PCB UNIT 1 EG,EP,EF,EB,EC (RTL) E.S.D. R3911 ERJ2GEJ331 M.RESISTOR CH 1/16W 330 1
■ VEP03H87A FLASH PCB UNIT 1 (RTL) E.S.D. R3912 ERJ2GEJ333 M.RESISTOR CH 1/16W 33K 1
■ VEP20C84A FRONT PCB UNIT 1 (RTL) E.S.D. R3913 D0GB150JA057 M.RESISTOR CH 1/10W 15 1
■ VEP29224A EVF BL PCB UNIT 1 (RTL) E.S.D. R3914 ERJ3GEY0R00 M.RESISTOR CH 1/10W 0 1
■ VEP04956A MIC AMP PCB UNIT 1 (RTL) E.S.D. R7001 ERJ2GEJ683 M.RESISTOR CH 1/16W 68K 1
■ VEP27225A MF SENS PCB UNIT 1 (RTL) E.S.D. R7002 D1BD8203A119 SURFACE MOUNTING PRECISIO 1
■ VEP01A32A BATT CATCHER PCB UNIT 1 (RTL) E.S.D. R7003 ERJ2RHD222 M.RESISTOR CH 1/16W 2.2K 1
■ VEP26330A MONITOR PCB UNIT 1 (RTL) E.S.D. R7004 ERJ8GEYJ105V M.RESISTOR CH 1/4W 1M 1
■ VEP04957A MIC AMP FPC UNIT 1 (RTL) E.S.D. R7006 ERJ2RHD471X M.RESISTOR CH 1/16W 470 1
■ VEP20C85A CAM FUNC PCB UNIT 1 (RTL) R7007 ERJ3GEYJ104 M.RESISTOR CH 1/10W 100K 1
■ VEP06G50A SIDE R OP PCB UNIT 1 (RTL) E.S.D. R7011 ERJ3GEYJ104 M.RESISTOR CH 1/10W 100K 1
R7015 ERJ3GEYJ560 M.RESISTOR CH 1/10W 56 1
 R7099 D1JBR102A006 M.RESISTOR CH 1/16W 1K 1
■ VEP03H87A FLASH PCB UNIT (RTL) E.S.D. RX3901 EXB28V103JX RESISTOR NETWORKS 1
C3302 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1 T7001 G5DYZ0000025 TRANSFOMER 1
C3303 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1
C3351 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C3901 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1
C3902 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1 ■ VEP20C84A FRONT PCB UNIT (RTL) E.S.D.
C3903 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1
C3904 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1 C4901 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1
C3905 ECJ0EC1H220J C.CAPACITOR CH 50V 22P 1 C4902 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1
C3906 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1 C4903 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C3907 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1 C4905 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1
C3910 F3G0J107A017 C.CAPACITOR CH 6.3V 100U 1 C4906 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1
C3911 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C4908 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C3950 F1G1A104A012 C.CAPACITOR CH 10V 0.1U 1 C4909 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C7001 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C4910 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1
C7002 ECJ0EC1H150J C.CAPACITOR CH 50V 15P 1 C4913 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1
C7003 F1J1A106A043 C.CAPACITOR CH 10V 10U 1 C4923 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C7005 F1K2E4730005 C.CAPACITOR 250V 0.047U 1 C6401 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1
C7010 F1K2E223A004 C.CAPACITOR 250V 0.022U 1 C6405 F1G1A104A012 C.CAPACITOR CH 10V 0.1U 1
D7002 B0ECGP000006 DIODE 1 E.S.D. D6401 B3AAB0000334 LED 1 E.S.D.
D7003 DA2JF8100L DIODE 1 E.S.D. D6402 B3ADB0000147 DIODE 1 E.S.D.
HS3901 K1NA09E00115 SD CARD SLOT 1 FP6400 K1MY08BA0370 CONNECTOR 8P 1
FP6402 K1MY06BA0370 CONNECTOR 6P 1
IC3351 L2EE00000011 IC 1 E.S.D. FP6403 K1MN33AA0094 CONNECTOR 33P 1
IC7001 C0ZBZ0001710 IC 1 E.S.D.
IR6401 B3RBB0000013 REMOTE SENSOR 1
JK3301 K2HZ112E0001 D-TERMINAL 1
JK4901 K2HC104B0047 JK, EXT MIC 1
L7001 G1C470MA0249 CHIP INDUCTOR 47UH 1 JK4902 K2HC106E0007 JACK, AV 1
LB3301 J0JCC0000408 FILTER 1 LB4923 J0JCC0000276 FILTER 1
LB3302 J0JCC0000408 FILTER 1 LB4924 J0JCC0000276 FILTER 1
LB3303 J0JCC0000408 FILTER 1 LB4926 J0JCC0000276 FILTER 1
LB3304 J0JCC0000276 FILTER 1 LB4927 J0JCC0000276 FILTER 1
LB3305 J0JCC0000276 FILTER 1 LB4928 J0JCC0000276 FILTER 1
LB3306 J0JCC0000276 FILTER 1 LB4929 J0JCC0000276 FILTER 1
LB4930 J0JHC0000078 FILTER 1
P7001 K1KA02B00292 CONNECTOR 2P 1
P7002 K1KA02BA0022 CONNECTOR 2P 1 Q4901 B1ABDF000017 TRANSISTOR 1 E.S.D.
Q4902 B1ADCF000161 TRANSISTOR 1 E.S.D.
PS7001 K1KB30AA0116 CONNECTOR 30P 1 Q4903 B1ABDF000017 TRANSISTOR 1 E.S.D.
Q4904 B1ADCF000161 TRANSISTOR 1 E.S.D.
Q3901 B1ADKB000015 TRANSISTOR 1 E.S.D. Q4907 B1ABDF000017 TRANSISTOR 1 E.S.D.
Q7005 B1JBLP000014 TRANSISTOR 1 E.S.D. Q4908 B1ABDF000017 TRANSISTOR 1 E.S.D.
Q6401 B1ADGD000005 TRANSISTOR 1 E.S.D.
R3311 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1
R3312 ERJ3RED750V SURFACE MOUNTING FI & D0 1 QR6401 B1GBCFJK0001 TRANSISTOR 1 E.S.D.
R3313 ERJ3RED750V SURFACE MOUNTING FI & D0 1 QR6403 B1GDCFYY0010 TRANSISTOR 1 E.S.D.
R3314 ERJ3RED750V SURFACE MOUNTING FI & D0 1
R3315 ERJ3RED750V SURFACE MOUNTING FI & D0 1 R4901 ERJ6GEYJ331V M.RESISTOR CH 1/8W 330 1
R3901 ERJ2GEJ220 M.RESISTOR CH 1/16W 22 1 R4902 ERJ2GEJ472 M.RESISTOR CH 1/10W 4.7K 1
R3902 ERJ2GEJ220 M.RESISTOR CH 1/16W 22 1 R4904 ERJ6GEYJ562V M.RESISTOR CH 1/8W 5.6K 1
R3903 ERJ2GEJ220 M.RESISTOR CH 1/16W 22 1 R4905 ERJ2GEJ471 M.RESISTOR CH 1/10W 470 1
R3904 ERJ2GEJ220 M.RESISTOR CH 1/16W 22 1 R4906 ERJ6GEYJ103V M.RESISTOR CH 1/8W 10K 1
R3905 ERJ2GEJ220 M.RESISTOR CH 1/16W 22 1 R4907 ERJ6GEYJ154V M.RESISTOR CH 1/8W 150K 1
R3906 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R4908 D0HB563ZA002 RESISTOR 1
R3907 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1 R4909 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1
S-24
