Panasonic HDC-HS700P - Page 75

HDC-HS700 vol.1
Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
R4910 ERJ2GEJ562 M.RESISTOR CH 1/10W 5.6K 1
R4911 ERJ2GEJ151 M.RESISTOR CH 1/10W 150 1 IC4801 C0ABBB000369 IC 1 E.S.D.
R4912 ERJ2GEJ471 M.RESISTOR CH 1/10W 470 1 IC4802 C0ABBB000369 IC 1 E.S.D.
R4913 ERJ6GEYJ103V M.RESISTOR CH 1/8W 10K 1 IC4803 C0ABBB000369 IC 1 E.S.D.
R4914 ERJ6GEYJ154V M.RESISTOR CH 1/8W 150K 1
R4915 D0HB563ZA002 RESISTOR 1 Q4801 B1ABDF000017 TRANSISTOR 1 E.S.D.
R4916 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1
R4917 ERJ2GEJ562 M.RESISTOR CH 1/10W 5.6K 1 R4801 ERJ6GEYG392 M.RESISTOR CH 1/10W 3.9K 1
R4918 ERJ2GEJ151 M.RESISTOR CH 1/10W 150 1 R4802 ERJ6GEYG392 M.RESISTOR CH 1/10W 3.9K 1
R4920 ERJ6GEYJ562V M.RESISTOR CH 1/8W 5.6K 1 R4803 ERJ6GEYG392 M.RESISTOR CH 1/10W 3.9K 1
R4922 ERJ2GEJ223 M.RESISTOR CH 1/16W 22K 1 R4804 ERJ6GEYG392 M.RESISTOR CH 1/10W 3.9K 1
R4923 ERJ2GEJ683 M.RESISTOR CH 1/16W 68K 1 R4805 ERJ6GEYG392 M.RESISTOR CH 1/10W 3.9K 1
R4924 ERJ2GEJ473Y M.RESISTOR CH 1/10W 47K 1 R4806 ERJ2GEJ183 M.RESISTOR CH 1/10W 18K 1
R4925 ERJ2GEJ2R2X M.RESISTOR CH 1/16W 2.2 1 R4807 ERJ2GEJ683 M.RESISTOR CH 1/16W 68K 1
R6402 ERJ2RKD330 M.RESISTOR CH 1/16W 33 1 R4808 ERJ2GEJ183 M.RESISTOR CH 1/10W 18K 1
R6403 ERJ2GEJ101 M.RESISTOR CH 1/10W 100 1 R4809 ERJ2GEJ683 M.RESISTOR CH 1/16W 68K 1
R6412 ERJ3GEYJ390 M.RESISTOR CH 1/10W 39 1 R4810 ERJ2GEJ183 M.RESISTOR CH 1/10W 18K 1
R6413 ERJ3GEYJ390 M.RESISTOR CH 1/10W 39 1 R4811 ERJ2GEJ683 M.RESISTOR CH 1/16W 68K 1
R6416 ERJ2GEJ473Y M.RESISTOR CH 1/10W 47K 1 R4812 ERJ2GEJ183 M.RESISTOR CH 1/10W 18K 1
R6417 ERJ2GEJ472 M.RESISTOR CH 1/10W 4.7K 1 R4813 ERJ2GEJ683 M.RESISTOR CH 1/16W 68K 1
R4814 ERJ2GEJ183 M.RESISTOR CH 1/10W 18K 1
VA4901 D4ED18R00008 VARISTOR 1 R4815 ERJ2GEJ683 M.RESISTOR CH 1/16W 68K 1
VA4902 D4ED18R00008 VARISTOR 1 R4816 ERJ2GEJ472 M.RESISTOR CH 1/10W 4.7K 1
R4817 ERJ2GEJ223 M.RESISTOR CH 1/16W 22K 1
R4818 ERJ2GEJ333 M.RESISTOR CH 1/16W 33K 1
R6405 ERJ2GEJ222 M.RESISTOR CH 1/10W 2.2K 1
■ VEP29224A EVF BL PCB UNIT (RTL) E.S.D.
ZB6401 K3ZZ00500014 BATTERY HOLDER 1
C801 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C802 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C803 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1
■ VEP27225A MF SENS PCB UNIT (RTL) E.S.D.
D801 B0BC6R2A0266 DIODE 1 E.S.D.
D803 B3AFB0000129 DIODE 1 E.S.D. FP6701 K1MY06BA0370 CONNECTOR 6P 1
D804 B0BC5R6A0266 DIODE 1 E.S.D.
Q6701 B3NBA0000017 TRANSISTOR 1 E.S.D.
FP801 K1MN21AA0094 CONNECTOR 21P 1 Q6702 B3NBA0000017 TRANSISTOR 1 E.S.D.
FP802 K1MY20BA0370 CONNECTOR 20P 1
R6701 ERJ2GEJ101 M.RESISTOR CH 1/10W 100 1
Q801 B1ABDF000017 TRANSISTOR 1 E.S.D. R6702 ERJ2GEJ101 M.RESISTOR CH 1/10W 100 1
R6703 ERJ2GEJ332 M.RESISTOR CH 1/16W 3.3K 1
R801 ERJ2RHD562 M.RESISTOR CH 1/16W 5.6K 1 R6704 ERJ2GEJ332 M.RESISTOR CH 1/16W 3.3K 1
R802 ERJ2RKD910 M.RESISTOR CH 1/16W 91 1
R803 ERJ2GEJ105 M.RESISTOR CH 1/10W 1M 1
R804 ERJ2RHD122 M.RESISTOR CH 1/16W 1.2K 1
R805 ERJ2RHD122 M.RESISTOR CH 1/16W 1.2K 1 ■ VEP01A32A BATT CATCHER PCB UNIT (RTL) E.S.D.
R806 ERJ2RHD222 M.RESISTOR CH 1/16W 2.2K 1
C851 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C852 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1
C853 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1
■ VEP04956A MIC AMP PCB UNIT (RTL) E.S.D. C854 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C855 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
 B6401 ML-614S/ZTK BATTERY 1 [ENERGY] C856 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C857 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C4801 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 C858 F1H0J225A002 C.CAPACITOR CH 6.3V 2.2U 1
C4802 ECJ0EC1H680J C.CAPACITOR CH 50V 68P 1 C859 F1H0J225A002 C.CAPACITOR CH 6.3V 2.2U 1
C4803 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 C860 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C4804 ECJ0EC1H680J C.CAPACITOR CH 50V 68P 1 C861 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C4805 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 C862 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C4806 ECJ0EC1H680J C.CAPACITOR CH 50V 68P 1 C863 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1
C4807 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 C864 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C4808 ECJ0EC1H680J C.CAPACITOR CH 50V 68P 1 C865 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
C4809 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1 C6301 F1G1A104A012 C.CAPACITOR CH 10V 0.1U 1
C4810 ECJ0EC1H680J C.CAPACITOR CH 50V 68P 1 C6302 F1G1A104A012 C.CAPACITOR CH 10V 0.1U 1
C4811 F1G1H4710004 C.CAPACITOR CH 50V 470P 1 C6306 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C4812 F1G1H4710004 C.CAPACITOR CH 50V 470P 1 C6307 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C4813 F1G1H4710004 C.CAPACITOR CH 50V 470P 1 C6308 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1
C4814 F1G1H4710004 C.CAPACITOR CH 50V 470P 1 C6309 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1
C4815 F1G1H4710004 C.CAPACITOR CH 50V 470P 1 C6310 F3F0J476A032 C.CAPACITOR CH 25V 0.01U 1
C4816 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1
C4817 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1 FP6301 K1MN23AA0035 CONNECTOR 23P 1
C4818 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 FP6302 K1MY08BA0370 CONNECTOR 8P 1
FP4801 K1MY08BA0370 CONNECTOR 8P 1 IC851 C1AB00002388 IC 1 E.S.D.
FP4802 K1MN21AA0035 CONNECTOR 21P 1 IC6301 EWTS9CVE11 IC 1 E.S.D.
FP4803 K1MY12BA0370 CONNECTOR 12P 1 IC6302 C0DBGFC00009 IC 1 E.S.D.
FP4804 K1MY04BA0370 CONNECTOR 4P 1
S-25
