HDC-HS700 vol.1
Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
JK6751 K4ZZ04000049 JACK, BATTERY CATCH 1
■ VEP06G50A SIDE R OP PCB UNIT (RTL) E.S.D.
PP601 K1KB50AA0094 CONNECTOR 50P 1
FP6501 K1MN08A00072 CONNECTOR 8P 1
R851 ERJ2GEJ102X M.RESISTOR CH 1/16W 1K 1
R852 ERJ2RHD511 M.RESISTOR CH 1/16W 510 1 P6501 K1KA02BA0014 CONNECTOR 2P 1
R853 ERJ2RHD102X M.RESISTOR CH 1/16W 1K 1
PS6201 K1KB40A00128 CONNECTOR 40P 1
VA6751 D4ED18R00008 VARISTOR 1 PS6501 K1KA03BA0014 CONNECTOR 3P 1
S6501 K0F111A00589 SWITCH 1
S6502 K0F111A00589 SWITCH 1
■ VEP26330A MONITOR PCB UNIT (RTL) E.S.D.
C502 F1G1A104A012 C.CAPACITOR CH 10V 0.1U 1
C504 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1
C505 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1
C506 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1
C507 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1
C901 F1G1E1040001 C.CAPACITOR CH 25V 0.1U 1
C902 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1
C903 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C905 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C906 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1
C907 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C908 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1
C909 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C910 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1
C911 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C912 F1H1E105A116 C.CAPACITOR CH 25V 1U 1
C913 F1H1E105A116 C.CAPACITOR CH 25V 1U 1
C914 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C915 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C916 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1
C917 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1
C918 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1
C919 F1G1C104A080 C.CAPACITOR CH 16V 0.1U 1
D901 B0BC016A0267 DIODE 1 E.S.D.
D902 B3AFB0000321 DIODE 1 E.S.D.
D903 B3AFB0000321 DIODE 1 E.S.D.
D904 B3AFB0000321 DIODE 1 E.S.D.
D905 B3AFB0000321 DIODE 1 E.S.D.
D906 B0JCCD000003 DIODE 1 E.S.D.
D907 B0JCCD000003 DIODE 1 E.S.D.
FP901 K1MY16BA0159 CONNECTOR 16P 1
FP902 K1MY12BA0159 CONNECTOR 12P 1
FP903 K1MY04BA0370 CONNECTOR 4P 1
FP904 K1MY41BA0369 CONNECTOR 41P 1
FP905 K1MN04B00071 CONNECTOR 4P 1
R506 ERJ2GEJ104 M.RESISTOR CH 1/10W 100K 1
R507 ERJ2GEJ104 M.RESISTOR CH 1/10W 100K 1
R901 ERJ2GEJ824 M.RESISTOR CH 1/16W 820K 1
R902 ERJ3GEY0R00 M.RESISTOR CH 1/10W 0 1
R903 ERJ3GEY0R00 M.RESISTOR CH 1/10W 0 1
■ VEP04957A MIC AMP FPC UNIT (RTL) E.S.D.
PP6003 K1KA20A00275 CONNECTOR 20P 1
■ VEP20C85A CAM FUNC PCB UNIT (RTL)
S6601 K0F111A00589 SWITCH 1
S-26
