Panasonic HDC-HS700P - Page 77

HDC-HS700 vol.1
Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
B96 XQS2+A35FN SCREW 1
8 VEP79258A HDD FPC UNIT 1 (RTL) E.S.D.
33 VGK3616 MF RING 1
34 VYK3Q71 BARIA CASE UNIT 1
35 VGL1326 TARY PANEL LIGHT 1
36 VGL1309 AF PANEL LIGHT 1
37 N9ZZ00000415 BARRIER MOTOR UNIT 1
38 EFN-MVBH7ZC FLASH 1
39 VGQ0K50 LENS ORNAMENT SHEET 1
40 VGQ0K49 MF FRONT FRAME 1
41 VGQ0K51 MF SHEET 1
42 VGQ0K53 MF PCB HOLDER 1
43 VEP27225A MF SENS PCB UNIT 1 (RTL) E.S.D.
44 VWJ2134 MF SENS FPC 1
45 K0RE00900047 OPERATION BUTTON UNIT 1
46 VYK3Q41 TOP CASE UNIT 1
47 VMP9581 TOP FRAME 1
48 VEP20C85A CAM FUNC PCB UNIT 1 (RTL)
49 VGU0F89 CAMERA OP BUTTON 1
50 VGQ0K85 CAMERA OP CASE 1
51 VMP9616 CAMERA OP ANGLE 1
52 VGQ0K35 MIC CASE 1
53 VGQ0C85 MIC CUSHION (A) 1
54 VGQ0C86 MIC CUSHION (B) 1
55 VGQ0C87 MIC CUSHION (C) 1
56 VGQ0L66 MIC SHEET 1
57 VEP24186B ECM FPC UNIT 1
78 VEP04956A MIC AMP PCB UNIT 1 (RTL) E.S.D.
79 VEP04957A MIC AMP FPC UNIT 1 (RTL) E.S.D.
81 VYK3Q52 SIDE CASE (L) UNIT 1
82 VYK3Q31 SENSOR COVER UNIT 1
85 VEP20C84A FRONT PCB UNIT 1 (RTL) E.S.D.
91 VMP8492 SHOE ANGLE 1
92 VYK3Q72 HDD GND CASE UNIT 1
93 VGQ9672 GASKET 1
95 VMG1922 HDD CUSHION 1
96 VMG1922 HDD CUSHION 1
98 RFKV0224HDKT HDD 1
99 VGQ0M74 CUSHION 1
100 VGQ0M76 SHEET 1
B14 VHD1814 SCREW 1
B15 VHD1814 SCREW 1
B16 VHD1814 SCREW 1
B17 VHD1814 SCREW 1
B18 XQN16+BJ5FN SCREW 1
B19 XQN16+BJ5FN SCREW 1
B20 XQN16+BJ10FN SCREW 1
B21 XQN14+BJ5FN SCREW 1
B26 XQN16+B3FN SCREW 1
B27 XQN16+B3FN SCREW 1
B28 XQN16+BJ4FN SCREW 1
B29 XQN16+BJ4FN SCREW 1
B30 XQN16+BJ4FN SCREW 1
B31 XQN16+BJ4FN SCREW 1
B32 XQN16+BJ4FN SCREW 1
B33 XQN16+BJ4FN SCREW 1
B34 XQN16+BJ4FN SCREW 1
B35 XQN16+BJ4FN SCREW 1
B36 XQN16+BJ4FN SCREW 1
B37 XQN16+BJ4FN SCREW 1
B47 VHD1907 SCREW 1
B48 VHD1907 SCREW 1
B57 VHD2189 SCREW 1
B59 VHD2233 SCREW 1
B66 XQN16+B4FJK SCREW 1
B67 XQN16+B4FJK SCREW 1
B68 XQN16+B4FJK SCREW 1
B69 XQN16+B4FJK SCREW 1
B70 XQN16+B4FJK SCREW 1
B71 XQN16+B4FJK SCREW 1
B75 XQN16+B4FJK SCREW 1
B91 VHD1907 SCREW 1
B92 VHD1907 SCREW 1
B93 XQN16+BJ7FJK SCREW 1
B94 XQS2+A35FN SCREW 1
B95 XQS2+A35FN SCREW 1
