Installation
11
For Fax Advantage assistance, call 1-800-435-7329.
5 Turn the gear of blue core in the direction of
the arrow.
L Make sure that the ink film is wrapped
around the blue core at least once.
6 Close the back cover securely by pushing
down on the dotted area at both ends (1).
Close the front cover securely (2).
Ink film
Gear of blue core
Slack
Reverse
Correct
Blue core
The ink film is not wrapped
around the blue core.
Incorrect
Tight
1 turn
Dotted
area
Back cover
Front cover
1
2
To Next Page
