12. Paper Jams
79
2 Remove the jammed paper.
Case 1:
When the recording paper has jammed near the
drum and toner unit:
1. Pull the paper input tray completely out.
2. Remove the jammed paper (1) carefully by
pulling it upwards.
Remove the jammed paper (1) carefully by
pulling it toward you.
3. Insert the paper input tray into the unit.
Case 2:
When the recording paper has jammed near the
fuser unit:
1. Lift both green levers (1) until they stop.
2. Remove the jammed paper (1) carefully by
pulling it upwards.
3. Push back the green levers (1) to the original
position.
1
1
1
1
1
