Case 3:
When the recording paper has jammed near the fuser
unit:
1. Open the top cover (A) by holding the indentations
(B) on both sides of the unit.
D
A
B
B
C
Caution:
R The fuser unit (C) gets hot. Do
not touch it.
Note:
R Do not touch the transfer roller (D).
2. Lift both green levers (E) until they stop.
E
3.
Remove the jammed paper (F) carefully by pulling it
upwards.
F
4.
Push back the green levers (G) to the original
position.
G
88
12. Paper Jams
