6 Open the top cover (H) by holding the indentations
(I) on both sides of the base unit.
Note:
R Do not touch the transfer roller (J).
R If the lower glass (K) is dirty, clean it with a soft
and dry cloth.
7 Install the drum and toner cartridge (L) by holding
the tabs.
R Make sure that the arrows (M) match, to install
the drum and toner cartridge correctly.
For assistance, please visit http://www.panasonic.com/help
13
1. Introduction and Installation
