Panasonic KX-TCD535HK

104
Wall Mounting
Base Unit
This base unit can be mounted on the wall.
1
Pull down the handset hook until it locks, so
the tab holds the handset.
2
Press the tabs in the direction of the arrows ( ), then remove
the wall mounting adaptor ( ).
3
Connect the AC adaptor, then push the wall mounting adaptor in the direction of the
arrows ( ) and ( ).
• The word “UP WALL” should face upward.
1
2
11
2
1
2
To Power
Outlet
1
1
2
2
