8
Location of Controls
Base Unit
1 - LEFT SOFT KEY
2 - MIDDLE SOFT KEY
3 - RIGHT SOFT KEY
4 - PAGE/INTERCOM Button
5 -
NAVIGATOR KEY
6 - RECALL Button
7 - CLEAR Button
8 -
SPEAKERPHONE Button
9 -
REDIAL Button
10 -
MUTE Button
How to Use the Base Unit Soft Keys
The 3 soft keys are used to select functions displayed directly above the keys.
Functions displayed above the keys will change depending on the state of use.
For example, on the standby mode display, “ ”, “ ” and
“ ” are displayed above the soft keys.
Example: Standby Mode Display To operate “ ” (Phonebook),
press LEFT SOFT KEY.
To operate “ ” (Menu),
press MIDDLE SOFT KEY.
To operate “ ” (Caller ID List),
press RIGHT SOFT KEY.
When “ ” is displayed above a soft
key, the soft key has no function.
Ringer/In Use LED
1
2
3
4
5
6
7
8
9
10
Display
25.2 21:05
