Panasonic KX-TDA0141 - KX-TDA30 Connection for Specific Models

KX-TDA0155/KX-TDA0141 connecting to KX-TDA30
Signal Name
Signal Name
Pin No.
1
2
3
4
D1
D2
D1
D2
Pin No.
1
2
3
4
A Super Hybrid Port,
or DLC4/DLC8 card (RJ11)
CS (RJ11)
Signal Name
Signal Name
Pin No.
1
2
3
4
D1
D2
D2
Pin No.
1
2
3
4
D1
5
6
7
8
A Super Hybrid Port,
or DLC4/DLC8 card (RJ45)
CS (RJ11)
Cable Maximum Distance
ø 0.4 mm: 222 m
ø 0.5 mm: 347 m
ø 0.6 mm: 500 m
CAT 5: 347 m
Super Hybrid Port
Accessories and User-supplied Items for the CS
Accessories (included): Screws ´ 2, Washers ´ 2
User-supplied (not included): RJ11 connector
Note
For
details about the Super Hybrid Ports or DLC4/DLC8 card, refer to the Installation Manual for your
PBX.
Quick Installation Guide 39
7 Connecting a Cell Station to the PBX
