Connecting the CS
1. Connect the cable from the PBX to the CS.
KX-TDA0155/KX-TDA0156
RJ11 Modular
To PBX
KX-TDA0158
RJ45 Modular
To PBX
KX-TDA0141/KX-TDA0142
RJ11 Modular
To PBX
2. Pass the cable through the groove of the CS (in any direction depending on your preference).
KX-TDA0155/KX-TDA0156
To PBX
KX-TDA0158
To PBX
KX-TDA0141/KX-TDA0142
To PBX
Quick Installation Guide 47
7 Connecting a Cell Station to the PBX
