Panasonic KX-TDA100D Getting Started

2.1 Opening/Closing the Front Cover
Opening the Front Cover
1. Insert a flathead screwdriver into
the opening (on the left of the screw cover) and unlatch the screw cover.
Turn the screw anticlockwise to loosen.
2. Slide the front cover to the right until it stops, then lift the front cover.
Closing the Front Cover
1. Hook the front cover onto
the shelf (line up the protrusions on the cover with the receptacles on the shelf),
then slide the front cover to the left until it locks.
10 Getting Started
2.1 Opening/Closing the Front Cover
WWW.ERTEBATGROUP.COM
WWW.ERTEBATGROUP.COM

Panasonic KX-TDA100D Specifications

General

Type	Hybrid IP-PBX
Maximum Extensions	128
VoIP Compatibility	Yes
Power Supply	AC 100-240 V, 50/60 Hz
IP Extensions	64
DHCP Server	Yes
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
