Panasonic KX-UT133

Location of Controls
11
For KX-UT113/KX-UT123:
F
A EB CD
HI JG
KLM N P
R
O
ALCD (Liquid Crystal Display)
KX-UT136 is equipped with a 6-Line LCD.
KX-UT113/KX-UT123/KX-UT133 is equipped with a 3-Line LCD.
KX-UT123/KX-UT133/KX-UT136 is equipped with an LCD backlight.
BSoft Buttons (S1 to S4)
S1 to S4 (located below the display) are used to select the item displayed on
the bottom line of the display.
CNavigator Key
Used to adjust the volume or select desired items.
DENTER
Used to assign the selected item.
EMessage/Ringer Lamp*
1
When you receive a call or Hold Recall, the lamp ashes green.
When someone has left you a message, the lamp stays on red.
*1 If the unit is connected to a KX-NS1000 PBX, the Message/Ringer Lamp
shows the current status as follows:
– Green ashing: You are receiving an intercom call, or you are
receiving a Hold Recall or Transfer Recall from an extension.
– Red ashing: You are receiving an outside call, or you are receiving a
Hold Recall or Transfer Recall from an outside line.
– Red on: You have a message.
