Panasonic Lumix DMC-FX700 User Manual

Connecting to other equipment
- 174 -
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to
be printed out and instruct that printing be started from the camera’s LCD monitor.
•
Some printers can print directly from the card removed from the camera. For details, refer to
the operating instructions of your printer.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures from the built-in memory.
Perform the print quality and other settings at the printer before printing the pictures.
A USB connection cable (supplied)
• Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may be bent out of shape which may cause malfunction.)
B Align the marks, and insert.
• Use a battery with sufficient battery power or the AC adaptor (optional) and DC coupler
(optional). If the remaining battery power becomes low while the camera and the printer are
connected, the alarm beeps. If this happens during printing, stop printing at once. If not printing,
disconnect the USB connection cable.
Connect the camera to a printer via the USB connection cable A
(supplied).
• When the camera is connected to the printer, the cable disconnect prohibit icon [å]
appears. Do not disconnect the USB cable while [å] is displayed.
Touch [PictBridge(PTP)].
PictBridge(PTP)
PC
USB MODE
PLEASE SELECT
THE USB MODE

Panasonic Lumix DMC-FX700 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.33 \
Image formats supported	JPG
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	4320 x 3240
Optical zoom	5 x
Focal length range	4.3 - 21.5 mm
Minimum aperture number	-
Lens structure (elements/groups)	7/6
Maximum focal length (35mm film equiv)	120 mm
Minimum focal length (35mm film equiv)	24 mm
Interface	AV out, USB 2.0
Power source type	Battery
Normal focusing range	0.5 - ∞ (W), 1 - ∞ (T) m
Auto focusing (AF) modes	Continuous Auto Focus
Normal focusing range (wide)	0.5 - ∞ m
Auto Mode focusing range (tele)	1 - ∞ m
Auto Mode focusing range (wide)	0.03 - ∞ m
Flash modes	auto, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.8 m
Flash range (wide)	0.6 - 7.4 m
Internal memory	40 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum video resolution	1280 x 720 pixels
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Scene modes	Beach, Candlelight, Portrait, Self-portrait, Snow, Landscape (scenery)
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Shade
Camera playback	Slide show
Self-timer delay	- s
Product color	Black
Battery capacity	940 mAh
Battery life (CIPA standard)	300 shots
Bundled software	PHOTOfunSTUDIO 5.2 HD Edition, QuickTime, Adobe Reader
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s

Weight and Dimensions

Depth	24.5 mm
Width	103.5 mm
Height	55.8 mm
Weight	155 g
