Panasonic Lumix DMC-FX77 User Manual

- 11 -
Preparation
Inserting and Removing the Card (optional)/the
Battery
• Check that this unit is turned off.
• We recommend using a Panasonic card.
Slide the release lever in the direction of
the arrow and open the card/battery door.
• Always use genuine Panasonic batteries.
• If you use other batteries, we cannot guarantee
the quality of this product.
Battery: Being careful about the battery
orientation, insert all the way until you
hear a locking sound and then check that
it is locked by lever A.
Pull the lever A in the direction of the
arrow to remove the battery.
Card: Push it securely all the way until
you hear a “click” while being careful
about the direction in which you insert it.
To remove the card, push the card until it
clicks, then pull the card out upright.
B: Do not touch the connection terminals of the
card.
1:Close the card/battery door.
2:Slide the release lever in the direction
of the arrow.
Note
•
Remove the battery after use.
• The battery will be exhausted if left for a long period of time after being charged.
• Turn the camera off and wait for the “LUMIX” display on the LCD monitor to clear before
removing the card or battery. (Otherwise, this unit may no longer operate normally and the card
itself may be damaged or the recorded pictures may be lost.)
OPEN LOCK
CARD
OPEN LOCK

Panasonic Lumix DMC-FX77 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	12.5 MP
Image sensor size	1/2.33 \
Image formats supported	JPG
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2448 x 2448, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2992 x 2992, 3264 x 1840, 3264 x 2176, 3264 x 2448, 4000 x 2248, 4000 x 2672, 4000 x 3000
Digital zoom	4 x
Optical zoom	5 x
Combined zoom	20 x
Extra/Smart zoom	9.8 x
Focal length range	4.3 - 21.5 mm
Maximum aperture number	5.9
Minimum aperture number	2.5
Number of aspheric elements	3
Lens structure (elements/groups)	7/6
Maximum focal length (35mm film equiv)	130 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Centre weighted Auto Focus, Multi Point Auto Focus, Spot Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Light exposure control	Program AE
Camera shutter interval	0.3 s
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Red-eye reduction
Flash range (tele)	1 - 2.55 m
Flash range (wide)	0.6 - 5.9 m
Interface	PAL, USB2.0, mini HDMI
Digital SLR	No
Power source type	Battery
Camera shutter speed	8 - 1/4000, 15, 30, 60 s
Focal length (35mm film equivalent)	24 - 120 mm
Scene modes	Backlight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset
Image editing	Resizing, Trimming
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Languages support	DEU, ENG, ESP, FIN, FRE, ITA, SWE
Camera file system	Exif 2.3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	PAL
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.5 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Product color	Pink
Battery voltage	3.6 V
Battery capacity	660 mAh
Battery life (CIPA standard)	200 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 6.0 HD Lite Edition / QuickTime / Adobe Reader

Weight and Dimensions

Depth	20.6 mm
Width	99.7 mm
Height	55.2 mm
Weight	142 g
