Others
- 144 -
Message Display
Confirmation messages or error messages will be displayed on the screen in some cases.
The major messages are described below as examples.
[This picture is protected]
> Delete the picture after cancelling the protect setting. (P110)
[Some pictures cannot be deleted]/[This picture cannot be deleted]
Pictures not based on the DCF standard cannot be deleted.
> If you want to delete some pictures, format the card after saving necessary data on a PC
etc. (P45)
[Cannot be set on this picture]
[Title Edit], [Text Stamp] or [Print Set] cannot be set for pictures not based on the DCF
standard.
[Not enough space on built-in memory]/[Not enough memory on the card]
There is no space left on the built-in memory or the card.
When you copy pictures from the built-in memory to the card (batch copy), the pictures are
copied until the capacity of the card becomes full.
[Some pictures cannot be copied]/[Copy could not be completed]
The following pictures cannot be copied.
When a picture with the same name as the picture to be copied exists in the copy
destination. (Only when copying from a card to the built-in memory.)
Files not based on the DCF standard.
Moreover, pictures recorded or edited by other equipment may not be copied.
[Built-In Memory Error
Format built-in memory?]
This message will be displayed when you format the built-in memory on a PC.
> Format the built-in memory on the camera again. (P45) The data on the built-in memory
will be deleted.
[Memory card error.
This card cannot be used in this camera.
Format this card?]
It is a format that cannot be used with this unit.
> Insert a different card.
> Format the card again with the camera after saving necessary data on a PC etc. (P45)
Data will be deleted.
[Please turn camera off and then on again]/[System Error]
This message appears when the camera is not operating properly.
> Turn the camera off and on. If the message persists, contact the dealer or your nearest
Service Centre.

Table of Contents

Other manuals for Panasonic Lumix DMC-FX77

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FX77 and is the answer not in the manual?

Panasonic Lumix DMC-FX77 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels12.5 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2448 x 2448, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2992 x 2992, 3264 x 1840, 3264 x 2176, 3264 x 2448, 4000 x 2248, 4000 x 2672, 4000 x 3000
Digital zoom4 x
Optical zoom5 x
Combined zoom20 x
Extra/Smart zoom9.8 x
Focal length range4.3 - 21.5 mm
Maximum aperture number5.9
Minimum aperture number2.5
Number of aspheric elements3
Lens structure (elements/groups)7/6
Maximum focal length (35mm film equiv)130 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto
Auto focusing (AF) modesCentre weighted Auto Focus, Multi Point Auto Focus, Spot Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Light exposure controlProgram AE
Camera shutter interval0.3 s
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Flash off, Red-eye reduction
Flash range (tele)1 - 2.55 m
Flash range (wide)0.6 - 5.9 m
InterfacePAL, USB2.0, mini HDMI
Digital SLRNo
Power source typeBattery
Camera shutter speed8 - 1/4000, 15, 30, 60 s
Focal length (35mm film equivalent)24 - 120 mm
Scene modesBacklight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset
Image editingResizing, Trimming
Photo effectsBlack&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Languages supportDEU, ENG, ESP, FIN, FRE, ITA, SWE
Camera file systemExif 2.3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Motion JPEG frame rate30 fps
Video formats supportedAVCHD
Maximum video resolution1920 x 1080 pixels
Analog signal format systemPAL
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3.5 \
Display resolution (numeric)230000 pixels
Viewfinder typeNot available
USB version2.0
Product colorPink
Battery voltage3.6 V
Battery capacity660 mAh
Battery life (CIPA standard)200 shots
Cables includedAC, AV, USB
Bundled softwarePHOTOfunSTUDIO 6.0 HD Lite Edition / QuickTime / Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth20.6 mm
Width99.7 mm
Height55.2 mm
Weight142 g
