Recording
- 154 -
Perform these settings if you need to.
Using the [Custom] Menu
For details on how to select the [Custom] menu settings, refer to P60.
•
Refer to P132 for details.
• Refer to P65 for details.
• Refer to P103 for details.
• When the recorded picture and the histogram do not match each other under the
following conditions, the histogram is displayed in orange.
– When the Manual Exposure Assistance is other than [n0] during Exposure Compensation or
in the Manual Exposure Mode
– When the flash is activated
– When suitable exposure is not achieved with the flash closed
– When the brightness of the screen is not correctly displayed in dark places
• The histogram is an approximation in the Recording Mode.
• The histogram displayed in this camera does not match histograms displayed by picture editing
software used in PCs etc.
[Cust.Set Mem.]
[]/[]/[]
[Q.MENU/Fn1] —
[Fn Button Set] —
[Histogram]
This allows you to set either to display or not display the
histogram.
[ON]:
Position can be set by dragging the
histogram.
•
Direct touch operation is also possible
from the recording screen.
[OFF]
A histogram is a graph that displays brightness
along the horizontal axis (black to white) and the
number of pixels at each brightness level on the
vertical axis.
It allows you to easily check a picture’s exposure.
A dark
B optimal
C bright

Panasonic Lumix DMC-GF5 Specifications

General

Megapixel	12.1 MP
Camera type	SLR Camera Kit
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	13.06 MP
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	4.2 x
Focal length range	14 - 42 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	19/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Interface	USB 2.0
Power source type	Battery, USB
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/25 - 1/16000 s
Effective sensor resolution	12100000 pixels
Focal length (35mm film equivalent)	28 - 84 mm
Scene modes	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@28fps, 640x480@30fps
Audio system	Mono
Audio formats supported	AAC
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Magnification	0.16 x
USB version	2.0
Product color	White
Battery voltage	7.2 V
Battery capacity	940 mAh
Battery life (CIPA standard)	320 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope

Weight and Dimensions

Depth	36.8 mm
Width	107.7 mm
Height	66.6 mm
Weight	432 g
