Page #203 background imageLoading...
Page #203 background image
- 203 -
Others
Troubleshooting
First, try out the following procedures (P203212).
The battery is exhausted.
Charge the battery.
If you leave the camera on, the battery will be exhausted.
> Turn the camera off frequently by using the [Economy] etc. (P70)
If you connect to a TV compatible with VIERA Link with a HDMI mini cable (optional) and turn
off the power on the TV with the remote control for the TV, the power on this unit also turns off.
> If you are not using VIERA Link, set [VIERA Link] to [OFF]. (P72)
Insert the battery securely all the way in.
Is the subject focused?
> [Focus Priority] is set to [ON] at the time of purchase, and so you cannot take pictures until
the subject is in focus. If you want to be able to take a picture when you press the shutter
button fully even if the subject is not focused, set [Focus Priority] in the [Custom] menu to
[OFF]. (P156)
Picture might look whitish when lens or image sensor gets dirty with fingerprints or similar.
> If the lens is dirty turn the camera off and then gently wipe the lens surface with a soft, dry
cloth.
> Refer to P195 when the image sensor gets dirty.
If the problem is not resolved, it may be improved by selecting [Reset] (P73) on the
[Setup] menu.
Battery and power source
The camera cannot be operated even when it is turned on.
The camera turns off immediately after it is turned on.
This unit is turned off automatically.
Card/battery door does not close.
Recording
Taking pictures is not possible.
The shutter will not operate immediately when the shutter button is pressed.
The recorded picture is whitish.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GF5 and is the answer not in the manual?

Panasonic Lumix DMC-GF5 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeSLR Camera Kit
Sensor typeLive MOS
Image stabilizerYes
Total megapixels13.06 MP
Image sensor size4/3 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Extra/Smart zoom4.2 x
Focal length range14 - 42 mm
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Lens structure (elements/groups)19/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance0.3 m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
InterfaceUSB 2.0
Power source typeBattery, USB
Aperture range (F-F)3.5 - 5.6
Camera shutter speed1/25 - 1/16000 s
Effective sensor resolution12100000 pixels
Focal length (35mm film equivalent)28 - 84 mm
Scene modes-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@28fps, 640x480@30fps
Audio systemMono
Audio formats supportedAAC
Internal memory0 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)920000 pixels
Magnification0.16 x
USB version2.0
Product colorWhite
Battery voltage7.2 V
Battery capacity940 mAh
Battery life (CIPA standard)320 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Bundled softwarePHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth36.8 mm
Width107.7 mm
Height66.6 mm
Weight432 g
