Basic
- 54 -
Press [DISP.] to switch the monitor screen.
Screen will switch as follows:
A With information
¢1
B Detailed information display
¢2
(P193)
C Histogram display
¢2
(P193)
D Without information (Highlight display)
¢1, 2, 3, 4
E Without information
¢4
¢1 If approximately 1 minute elapses without an operation being performed, part of the display
will disappear. Press [DISP.] or touch the LCD monitor to make the display reappear.
¢2 It is not displayed during the Playback Zoom, while playing back a motion picture, or during
slide show.
¢3 This is displayed if [Highlight] (P155) in the [Custom] menu is set to [ON].
¢4 If no operation is performed for a number of seconds, [ ] and other touch icons will
disappear.
Histogram is displayed in R (red), G (green), B (blue), and Y (luminance) during the playback.
Using the Playback Zoom
Touch the part you want to enlarge firmly.
1k>2k>4k>8k>16k
You can also enlarge/reduce the picture by rotating the control dial.
When you change the magnification, the zoom position indication A
appears for about 1 second.
The more a picture is enlarged, the more its quality deteriorates.
You can move the enlarged part by dragging (P10) the screen.
Picture will return to the original size (1k) by touching [ ].
When you touch [ ], the magnification becomes lower.
Changing the information displayed on the playback screen
A
DISP.

2011.12. 1 10:00
6060
60
F3.5F3.5
F3.5
00
AWBAWBAWB
1/981/981/98
16
0
16
0
16
0
F3.5
60
1/98
ISO
160
0
100-0001
100-0001
F3.5
60
P
s
RGB
AFS
160
0
WBWB
ISOISO
AWB
STD.STD.STD.
10:00 DEC. 1.2012
