- 37 -
Basic
Recording Mode:
Taking Pictures using the Automatic Function
(Intelligent Auto Mode)
In this mode, the camera makes the optimal settings for the subject and scene, so we
recommend it when you wish to leave the settings to the camera and record without
thinking about them.
About [¦] button
By pressing the [¦] button, you can switch between the
Intelligent Auto ( or ) Mode of the Recording Mode
and other modes.
When the Recording Mode is or , the [¦] button
lights up. (Light turns off during recording)
To switch between and of the Recording Modes,
use the Recording Mode setting method of P29.
Set Recording Mode to [ ].
For details on setting up Recording Mode, refer to P29.
Defocus control can be set by touching [ ] on the recording screen
and then touching [ ]. (P43)
When the subject is touched, AF Tracking function works. It is also
possible by pressing the cursor button towards 2, and then pressing
the shutter button halfway. For details, refer to P92.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GF5 and is the answer not in the manual?

Panasonic Lumix DMC-GF5 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeSLR Camera Kit
Sensor typeLive MOS
Image stabilizerYes
Total megapixels13.06 MP
Image sensor size4/3 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Extra/Smart zoom4.2 x
Focal length range14 - 42 mm
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Lens structure (elements/groups)19/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance0.3 m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
InterfaceUSB 2.0
Power source typeBattery, USB
Aperture range (F-F)3.5 - 5.6
Camera shutter speed1/25 - 1/16000 s
Effective sensor resolution12100000 pixels
Focal length (35mm film equivalent)28 - 84 mm
Scene modes-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@28fps, 640x480@30fps
Audio systemMono
Audio formats supportedAAC
Internal memory0 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)920000 pixels
Magnification0.16 x
USB version2.0
Product colorWhite
Battery voltage7.2 V
Battery capacity940 mAh
Battery life (CIPA standard)320 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Bundled softwarePHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth36.8 mm
Width107.7 mm
Height66.6 mm
Weight432 g
