Panasonic Lumix DMC-GF5 User Manual

Others
- 190 -
Others
Optional accessories
You can easily widen the range of expression of the unit by installing a compatible lens.
•
We recommend that you use a conversion lens that is compatible with this unit. Use of a
non-compatible conversion lens or adaptor may result in breakage or damage to the lens.
• For details, refer to the operating instructions of the relevant conversion lenses.
The MC protector is a transparent filter which affects neither the colors nor the amount of
light, so it can always be used to protect the camera’s lens.
The ND filter reduces the amount of light to approximately 1/8th (equal to adjusting the
aperture value 3 increments) without affecting the color balance.
PL filter will suppress the reflected light from a metal or non spherical surfaces (flat
non-metallic surfaces, water vapour or invisible particles in the air), making it possible to
take a picture with enhanced contrast.
Note
•
When using the interchangeable lens (H-PS14042), turn the power switch [OFF] and ensure
the lens barrel is retracted before attaching or removing a filter.
• Do not attach multiple filters at the same time.
• You can attach the lens cap or the lens hood when the filter is attached.
• Refer to the instructions for each filter for details.
By connecting the AC adaptor (optional), and then plugging them into an electrical socket,
you can connect this unit to a PC or printer and use without worrying about the capacity of
the battery. To use the AC adaptor, a DC coupler (optional) is required.
Note
•
Always use a genuine Panasonic AC adaptor (optional).
• When using an AC adaptor, use the AC cable supplied with the AC adaptor.
• Also read the operating instructions for the AC adaptor and DC coupler.
Conversion lens (optional)
Wide conversion lens: Wide-angle effect allows a wider field of view.
Tele conversion lens: Telescopic effect allows a higher level of
magnification.
Macro conversion lens: Allows higher level of magnification of small
subjects.
Fish eye conversion lens: Enables recording of image with stretched
perspective.
Protector/Filters (optional)
AC adaptor (optional)/DC coupler (optional)

Panasonic Lumix DMC-GF5 Specifications

General

Megapixel	12.1 MP
Camera type	SLR Camera Kit
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	13.06 MP
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	4.2 x
Focal length range	14 - 42 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	19/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Interface	USB 2.0
Power source type	Battery, USB
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/25 - 1/16000 s
Effective sensor resolution	12100000 pixels
Focal length (35mm film equivalent)	28 - 84 mm
Scene modes	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@28fps, 640x480@30fps
Audio system	Mono
Audio formats supported	AAC
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Magnification	0.16 x
USB version	2.0
Product color	White
Battery voltage	7.2 V
Battery capacity	940 mAh
Battery life (CIPA standard)	320 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope

Weight and Dimensions

Depth	36.8 mm
Width	107.7 mm
Height	66.6 mm
Weight	432 g
