Panasonic Lumix DMC-GF5 User Manual

Others
- 202 -
[Memory Card Error]/[Memory card parameter error]/[This memory card cannot be
used]
> Use a card compatible with this unit. (P23)
• SD Memory Card (8 MB to 2 GB)
• SDHC Memory Card (4 GB to 32 GB)
• SDXC Memory Card (48 GB, 64 GB)
[Insert SD card again]/[Try another card]
•
An error has occurred accessing the card.
> Insert the card again.
> Insert a different card.
[Read Error/Write Error
Please check the card]
•
It has failed to read or write data.
> Remove the card after turning the power [OFF]. Insert the card again, turn the power on,
and try to read or write the data again.
• The card may be broken.
> Insert a different card.
[Cannot record due to incompatible format(NTSC/PAL) data on this card.]
> If you want to delete some pictures, format the card after saving necessary data on a PC
etc. (P73)
> Insert a different card.
[Motion recording was cancelled due to the limitation of the writing speed of the
card]
•
Use a card with SD Speed Class with “Class 4” or higher when recording motion pictures.
• In the event that it stops even after using a “Class 4” card or higher, the data writing speed has
deteriorated so it is recommended to make a backup and then format (P73).
• Depending on the type of the card, motion picture recording may stop in the middle.
[A folder cannot be created]
•
A folder cannot be created because there are no remaining folder numbers that can be used.
> Format the card after saving necessary data on a PC etc. (P73) If you execute [No.Reset]
in the [Setup] menu after formatting, the folder number is reset to 100. (P73)
[Picture is displayed for 16:9 TV]/[Picture is displayed for 4:3 TV]
•
Select [TV Aspect] in the [Setup] menu if you want to change the TV aspect. (P71)
• This message also appears when the USB connection cable is connected to the camera only.
In this case, connect the other end of the USB connection cable to a PC or a printer. (P182,
186)
[This battery cannot be used]
•
Use a genuine Panasonic battery. If this message is displayed even when a genuine
Panasonic battery is used, contact the dealer or your nearest Service Center.
• If the battery terminal is dirty, clean it and remove any objects.

Panasonic Lumix DMC-GF5 Specifications

General

Megapixel	12.1 MP
Camera type	SLR Camera Kit
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	13.06 MP
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	4.2 x
Focal length range	14 - 42 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	19/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Interface	USB 2.0
Power source type	Battery, USB
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/25 - 1/16000 s
Effective sensor resolution	12100000 pixels
Focal length (35mm film equivalent)	28 - 84 mm
Scene modes	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@28fps, 640x480@30fps
Audio system	Mono
Audio formats supported	AAC
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Magnification	0.16 x
USB version	2.0
Product color	White
Battery voltage	7.2 V
Battery capacity	940 mAh
Battery life (CIPA standard)	320 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope

Weight and Dimensions

Depth	36.8 mm
Width	107.7 mm
Height	66.6 mm
Weight	432 g
