Panasonic Lumix DMC-GF5 User Manual

- 159 -
Recording
• Imaging device and image processing is optimized when the camera is purchased. Use this
function when bright spots that do not exist in the subject get recorded.
• Turn the camera off and on after the pixels are corrected.
• Dust Reduction Function will operate automatically when the camera is turned on, but you can
use this function when you see dust. (P195)
• When using a Leica lens mount adaptor (DMW-MA2M, DMW-MA3R: optional), set it to [ON].
[Touch Scroll]
This allows you to set the speed of continuously forwarding or
rewinding pictures using touch operation.
[
H]: High speed
[
L]: Low speed
[Menu Resume]
Stores the location of the last-used menu item for each menu.
[ON]/[OFF]
[Pixel Refresh]
It will perform optimization of imaging device and image
processing.
[Sensor Cleaning]
Dust reduction to blow off the debris and dust that have affixed to
the front of the imaging device is performed.
[Shoot w/o Lens]
Sets whether or not the shutter can be released when no lens is
attached to the main body.
[ON]: Shutter will operate regardless of the lens on the unit.
[OFF]: You cannot press the shutter button when a lens is not
attached to the camera body or is not attached
correctly.

Panasonic Lumix DMC-GF5 Specifications

General

Megapixel	12.1 MP
Camera type	SLR Camera Kit
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	13.06 MP
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	4.2 x
Focal length range	14 - 42 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	19/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Interface	USB 2.0
Power source type	Battery, USB
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/25 - 1/16000 s
Effective sensor resolution	12100000 pixels
Focal length (35mm film equivalent)	28 - 84 mm
Scene modes	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@28fps, 640x480@30fps
Audio system	Mono
Audio formats supported	AAC
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Magnification	0.16 x
USB version	2.0
Product color	White
Battery voltage	7.2 V
Battery capacity	940 mAh
Battery life (CIPA standard)	320 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope

Weight and Dimensions

Depth	36.8 mm
Width	107.7 mm
Height	66.6 mm
Weight	432 g
