Panasonic Lumix DMC-GF5 User Manual

- 183 -
Connecting to other equipment
Note
•
“PHOTOfunSTUDIO” is not compatible with Mac.
• Use a battery with sufficient battery power or the AC adaptor (optional). If the remaining battery
power becomes low while the camera and the PC are communicating, the status indicator
blinks and the alarm beeps.
Refer to
“Disconnecting the USB connection cable safely” (P184) before disconnecting the
USB connection cable. Otherwise, data may be destroyed.
• Before connecting or disconnecting the AC adaptor (optional), turn the camera off.
• Before inserting or removing a card, turn the camera off and disconnect the USB connection
cable. Otherwise, data may be destroyed.
∫ Copying to a PC without using “PHOTOfunSTUDIO”
If you are not able to install “PHOTOfunSTUDIO”, you can copy files and folders to your
PC by dragging and dropping files from this unit.
• The content (folder structure) on the card of this unit is as follows.
• AVCHD motion pictures may not be imported correctly when copied as files or folder. We
recommend using “PHOTOfunSTUDIO” on the CD-ROM (supplied) for importing files. Refer to
P181 for details.
• A new folder is created when pictures are taken in the following situations.
– After [No.Reset] (P73) in the [Setup] menu has been executed
– When a card containing a folder with the same folder number has been inserted (such as
when pictures were taken using another maker of camera)
– When there is a picture with file number 999 inside the folder
For Windows: A drive ([Removable Disk]) is displayed in [Computer]
For Mac: A drive ([LUMIX], [NO_NAME] or [Untitled]) is displayed on the
desktop
• Card
DCIM: Images
1 Folder number
2 Color space P: sRGB
_: AdobeRGB
3 File number
4 JPG: Still pictures
MP4: [MP4] Motion pictures
RW2: Pictures in RAW files
MPO: 3D pictures
MISC: DPOF print
Favorite
AVCHD: [AVCHD] Motion pictures
AVCHD
DCIM
100_PANA
101_PANA
999_PANA
PRIVATE
MISC

Panasonic Lumix DMC-GF5 Specifications

General

Megapixel	12.1 MP
Camera type	SLR Camera Kit
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	13.06 MP
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	4.2 x
Focal length range	14 - 42 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	19/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Interface	USB 2.0
Power source type	Battery, USB
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/25 - 1/16000 s
Effective sensor resolution	12100000 pixels
Focal length (35mm film equivalent)	28 - 84 mm
Scene modes	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@28fps, 640x480@30fps
Audio system	Mono
Audio formats supported	AAC
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Magnification	0.16 x
USB version	2.0
Product color	White
Battery voltage	7.2 V
Battery capacity	940 mAh
Battery life (CIPA standard)	320 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope

Weight and Dimensions

Depth	36.8 mm
Width	107.7 mm
Height	66.6 mm
Weight	432 g
