Panasonic Lumix DMC-GF5 User Manual

Basic
- 44 -
Note
•
On the Defocus Control setting screen of Intelligent Auto ( or ) Mode, the AF Mode is
[Ø].
You can set the location of the AF area by touching the screen. (Size cannot be changed)
• After beginning motion picture recording, the amount of defocus will vary depending on the
recording conditions.
• Aperture is controlled within the range of appropriate exposure during the recording of a motion
picture, so the aperture may not actually change even when the slide bar is moved depending
on the brightness of the subject, and the blurriness may not change.
(When recording dark scenes in rooms etc., the aperture may remain fully open and leave the
defocus state unchanged, even when you move the slide bar from end to end.)
• Depending on the lens used, you may hear a sound from the lens when the Defocus Control is
used, but this is due to operation of the aperture of the lens and it is not a malfunction.
• Depending on the lens used, operational sound of the Defocus Control may be recorded during
the recording of a motion picture when the function is used.
• Depending on the lens used, Defocus Control function may not operate.
Refer to the website for compatible lenses.
• In [Miniature Effect] of Creative Control Mode, Defocus Control cannot be used.

Panasonic Lumix DMC-GF5 Specifications

General

Megapixel	12.1 MP
Camera type	SLR Camera Kit
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	13.06 MP
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Extra/Smart zoom	4.2 x
Focal length range	14 - 42 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	19/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Interface	USB 2.0
Power source type	Battery, USB
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/25 - 1/16000 s
Effective sensor resolution	12100000 pixels
Focal length (35mm film equivalent)	28 - 84 mm
Scene modes	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@28fps, 640x480@30fps
Audio system	Mono
Audio formats supported	AAC
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Magnification	0.16 x
USB version	2.0
Product color	White
Battery voltage	7.2 V
Battery capacity	940 mAh
Battery life (CIPA standard)	320 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope

Weight and Dimensions

Depth	36.8 mm
Width	107.7 mm
Height	66.6 mm
Weight	432 g
