Basic
- 72 -
This will work when the HDMI mini cable (optional) is connected.
Refer to P179 for details.
This will work when the HDMI mini cable (optional) is connected.
Refer to P175 for the method to play back 3D pictures in 3D.
Refer to P51 for information about how to play back pictures.
When you play back pictures on a PC, they cannot be displayed in the rotated direction unless
the OS or software is compatible with Exif. Exif is a file format for still pictures which allows
recording information etc. to be added. It was established by “JEITA (Japan Electronics and
Information Technology Industries Association)”.
It may not be possible to rotate pictures that have been recorded with other equipment.
The display is not rotated during Multi Playback.
[VIERA Link]
Set so this unit can be controlled by the remote control of the
VIERA equipment by automatically coupling this unit with the
VIERA Link compatible equipment using HDMI mini cable
(optional).
[ON]: Remote control operation of the VIERA Link
compatible equipment is enabled. (Not all operations
are possible)
Button operation of the main unit will be limited.
[OFF]: Operation is performed with the buttons on this unit.
[3D Playback]
Set the output method for 3D pictures.
[]: Set when connecting to a 3D compatible television.
[]: Set when connecting to a television not compatible
with 3D.
Set this when you would like to view pictures in 2D
(conventional image) on a 3D compatible television.
[Rotate Disp.]
This mode allows you to display pictures vertically if they were
recorded holding the camera vertically.
[ON]/[OFF]

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GF5 and is the answer not in the manual?

Panasonic Lumix DMC-GF5 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeSLR Camera Kit
Sensor typeLive MOS
Image stabilizerYes
Total megapixels13.06 MP
Image sensor size4/3 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Extra/Smart zoom4.2 x
Focal length range14 - 42 mm
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Lens structure (elements/groups)19/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance0.3 m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
InterfaceUSB 2.0
Power source typeBattery, USB
Aperture range (F-F)3.5 - 5.6
Camera shutter speed1/25 - 1/16000 s
Effective sensor resolution12100000 pixels
Focal length (35mm film equivalent)28 - 84 mm
Scene modes-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@28fps, 640x480@30fps
Audio systemMono
Audio formats supportedAAC
Internal memory0 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)920000 pixels
Magnification0.16 x
USB version2.0
Product colorWhite
Battery voltage7.2 V
Battery capacity940 mAh
Battery life (CIPA standard)320 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Bundled softwarePHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth36.8 mm
Width107.7 mm
Height66.6 mm
Weight432 g
