- 75 -
Recording
Preventing jitter (camera shake)
When the jitter alert [ ] appears, use [Stabilizer], a tripod or the self-timer (P88).
Shutter speed will be slower particularly in the following cases. Keep the camera still from the
moment the shutter button is pressed until the picture appears on the screen. We recommend
using a tripod.
Slow Sync.
Slow Sync./Red-Eye Reduction
[Clear Nightscape], [Cool Night Sky], [Warm Glowing Nightscape], [Artistic Nightscape],
[Glittering Illuminations] and [Clear Night Portrait] in Scene Guide Mode
When you set to a slow shutter speed
Note
When using an optional interchangeable lens with an O.I.S. switch, it is possible to set to
enable the Optical Image Stabilizer by switching the O.I.S. switch on the lens to [ON]. (At the
time of purchase, it is initially set to [ ].)
It is recommended to disable the Optical Image Stabilizer when using a tripod. [ ] is
displayed on the screen at that time.
The stabilizer function may not be effective in the following cases. Be careful of camera jitter
when you press the shutter button.
When there is a lot of jitter.
When the zoom magnification is high.
When using the Digital Zoom.
When taking pictures while following a moving subject.
When the shutter speed becomes slower to take pictures indoors or in dark places.
The panning effect in [ ] is more difficult to achieve in the following cases.
In brightly lit places such as in broad daylight on a summer’s day
When the shutter speed is faster than 1/100th of a second.
When you move the camera too slowly because the subject is moving slowly. (The
background will not become a blur.)
When the camera does not keep up with the subject satisfactorily

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GF5 and is the answer not in the manual?

Panasonic Lumix DMC-GF5 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeSLR Camera Kit
Sensor typeLive MOS
Image stabilizerYes
Total megapixels13.06 MP
Image sensor size4/3 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)1600 x 1064, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2112 x 2112, 2816 x 1584, 2816 x 1880, 2816 x 2112, 2992 x 2992, 4000 x 2248, 4000 x 2672, 4000 x 3000
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Extra/Smart zoom4.2 x
Focal length range14 - 42 mm
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Lens structure (elements/groups)19/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus
Closest focusing distance0.3 m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
InterfaceUSB 2.0
Power source typeBattery, USB
Aperture range (F-F)3.5 - 5.6
Camera shutter speed1/25 - 1/16000 s
Effective sensor resolution12100000 pixels
Focal length (35mm film equivalent)28 - 84 mm
Scene modes-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@28fps, 640x480@30fps
Audio systemMono
Audio formats supportedAAC
Internal memory0 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)920000 pixels
Magnification0.16 x
USB version2.0
Product colorWhite
Battery voltage7.2 V
Battery capacity940 mAh
Battery life (CIPA standard)320 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Bundled softwarePHOTOfunSTUDIO 8.2 AE SILKYPIX Developer Studio 3.1 SE Super LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth36.8 mm
Width107.7 mm
Height66.6 mm
Weight432 g
