Preparation
Preparation
Attaching/Detaching the Lens
• Check that the camera is turned off.
• Change lenses where there is not a lot of dirt or dust. Refer to P177, P178 when dirt or dust
gets on the lens.
Turn the lens rear cap A and the body cap B in the direction of the
arrow to detach them.
• Do not put your hands inside the mount.
Align the lens fitting marks C (red
marks) on the camera body and the lens
and then rotate the lens in the direction
of the arrow until it clicks.
• Do not press the lens release button D when you
attach a lens.
• Do not try to attach the lens when holding it at an
angle to the camera body as the lens mount may
get scratched.
Detach the lens cap.
Attaching a lens to the camera body
