Panasonic Lumix DMC-GH4 Basic Owner's Manual

24
Preparation
VQT5H68 (ENG)
Even when the camera is operated using the touch screen, it is
possible to operate with the cursor button and [MENU/SET]
button if a guide like the one shown on the right is displayed.
Even on menu screens etc. on which the guide is not displayed,
you can make settings and selections by operating the buttons.
•
By assigning [Cursor Button Lock] to a function button, you can disable the cursor buttons, the
[MENU/SET] button, and the control dial. (P85)
Press [DISP.] to switch the information displayed on the
screen.
•
Screen will switch as follows:
(Example of monitor display)
¢1 It is displayed when the [Monitor Info. Disp.] of the [Custom] menu is set to [ON]. (P103)
Settings can be adjusted directly by touching each of the items displayed on the screen.
• If you set [Guide Line] in the [Custom] menu, the guide lines are displayed. (P103)
• If no operation is performed, part of the information on the screen will gradually become darker
after approximately 10 seconds has passed, and will no longer be displayed after
approximately 1 minute has passed. Pressing the [DISP.] button or touching the monitor will
make the display reappear. This operation is to prevent screen burn-in and is not a malfunction.
[DISP.] button (Switching the displayed information)
In Recording Mode
With information
Without
information
With information
(tilt sensor
display)
Without
information (tilt
sensor display)
Turned off
On-monitor
recording
information
¢1
ュリヴヱハ
98
98
98
AFS
AFS
FHD
MOV
24
p
L
4:3
0
98
98
98
AFS
AFS
FHD
MOV
24
p
L
4:3
0
AFSAFS
98
AWB
0 0
0
Fn
ISO
AUTO
Wi-Fi
L
4:3
DMC-GH4_PPC-VQT5H68_eng.book 24 ページ ２０１４年３月１２日 水曜日 午後１０時３５分

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
