Panasonic Lumix DMC-GH4 Basic Owner's Manual

54
Recording
VQT5H68 (ENG)
Compensating the Exposure
Use this function when you cannot achieve appropriate exposure due to the difference in
brightness between the subject and the background.
1
Press [ ].
2
Rotate the rear dial or the front dial to
compensate the exposure.
• When not adjusting the setting, select [n0]
3
Press [ ] to set.
• You can also press the shutter button halfway to set.
Selecting the Method for Measuring Brightness
([Metering Mode])
Type of optical measurement to measure brightness can be changed.
Applicable modes:
Applicable modes:
> [Rec] > [Metering Mode]
[]
(Multiple)
This is the method in which the camera measures the most suitable
exposure by judging the allocation of brightness on the whole screen
automatically. Usually, we recommend using this method.
[]
(Center weighted)
This is the method used to focus on the subject on the center of the
screen and measure the whole screen evenly.
[]
(Spot)
This is the method to measure the subject in the spot
metering target A.
+1+1 +2+2 +3+3 +4+4 +5+5
-
5
-
5
-
4
-
4
-
3
-
3
-
2
-
2
-
1
-
100
0
0
0 +5
+5
+5
MENU
DMC-GH4_PPC-VQT5H68_eng.book 54 ページ ２０１４年３月１２日 水曜日 午後１０時３５分

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
