92
Others
VQT5B20 (ENG)
Interchangeable Lens H-FS1442A
“LUMIX G VARIO
14–42 mm/F3.5–5.6 II
ASPH./MEGA O.I.S.”
Focal length f=14 mm to 42 mm
(35 mm film camera
equivalent: 28 mm to 84 mm)
Aperture type 7 diaphragm blades/circular
aperture diaphragm
Aperture range F3.5 (Wide) to F5.6 (Tele)
Minimum aperture
value
F22
Lens construction 9 elements in 8 groups
(2 aspherical lenses)
In focus distance 0.2 m to ¶ (from the focus
distance reference line) (focal
length 14 mm to 20 mm),
0.3 m to ¶ (from the focus
distance reference line) (focal
length 21 mm to 42 mm)
Maximum image
magnification
0.17k (35 mm film camera
equivalent: 0.34k)
Optical Image
Stabiliser
Available
[O.I.S.] switch None (Setting of the
[Stabilizer] is done in [Rec]
menu.)
Mount “Micro Four Thirds Mount”
Angle of view 75x (Wide) to 29x (Tele)
Filter diameter 46 mm
Max. diameter Approx. 56 mm
Overall length Approx. 49 mm
(from the tip of the lens to the
base side of the lens mount)
Mass Approx. 110 g
DMC-GX7K&GX7GN-VQT5B20_eng.book 92 ページ ２０１３年７月２２日 月曜日 午後２時５０分
