Preparations
18
Speaker
Be careful not to cover the speaker
with your finger. Doing so may make
sound difficult to hear.
19
Tripod mount
Do not attach to a tripod with a 5.5 mm
(0.22 inch) or longer screw. Doing so
may damage this unit.
It may not be possible to attach certain
types of tripods properly.
20
DC coupler cover
• Open this cover to use an AC
adaptor (optional) and DC coupler
(optional) in place of the battery.
• Always use a genuine Panasonic
AC adaptor (DMW-AC10E:
optional).
• When using an AC adaptor, use the
AC Mains Lead supplied with the AC
adaptor.
• When using an AC adaptor
(DMW-AC10E: optional), ensure
that the Panasonic DC coupler
(DMW-DCC11: optional) and AC
adaptor are used.
21
Release lever (→16)
22
Card/Battery door (→16)
(Bottom)
18 20 2119 22
23
Viewfinder (LVF) (→24)
In this manual, “viewfinder” is used to
indicate the LVF.
24
Eye Sensor (→24)
25
Diopter adjustment dial (→24)
26
[LVF] button (→24) /
[Fn3] button (→21)
27
Strap eyelet (→13)
28
Monitor
29
[HDMI] socket (→71)
30
[AV OUT/DIGITAL] socket (→71, 74)
27
29
30
2523 26
28
24
