Panasonic Lumix DMC-LX15 User Manual

123
SQW0724
4K Photo and Drive Settings
Adjusting the focus after recording ([Post Focus]/[Focus Stacking])
Select the focus point and save the picture ([Post Focus])
1
On the playback screen, select the image with the
[ ] icon and press
• The same operation can be performed by touching [ ].
2
Touch the focus point
• If there are no pictures with the focus on the selected point, a red
frame will be displayed, and pictures cannot be saved.
• The edge of the screen cannot be selected.
Operation Touch operation Description
Touch
Select focus point
• No selection can be made while display is enlarged.
Enlarge display
Shrink display (when in enlarged display)
[Fn1]
Switches to [Focus Stacking] operation (→124)
[Fn2]
In-focus portions are highlighted with colour. ([Peaking])
• Switches in order of [
] → [ ] ([LOW])
→ [
] ([HIGH]).
[MENU/SET]
Save picture
• You can make fine adjustments to the focus by dragging the
slide bar during enlarged display. (The same operation can be
performed using
.)

Panasonic Lumix DMC-LX15 Specifications

General

Megapixels	20.1 MP
Lens	Leica DC Vario-Summilux
Aperture	f/1.4-2.8
Optical Zoom	3x
Connectivity	Wi-Fi
LCD Screen Resolution	1, 040, 000 dots
Continuous Shooting	10 fps
Built-in Flash	Yes
Battery Life	Approx. 260 shots
ISO Sensitivity	ISO 125-12800 (expandable to 80-25600)
Video Recording	4K UHD 30p, Full HD 60p
Display	3.0-inch TFT LCD
Focal Length	24-72mm (35mm equivalent)
Shutter Speed	60 - 1/4000 sec
Focus Points	49 points
Battery Type	Li-ion Battery Pack (7.2V, 680mAh)
Dimensions	105.5 x 60 x 42 mm
Weight	310 g (with battery and SD card)
Sensor Type	1-inch High Sensitivity MOS Sensor
Image Stabilization	5-axis Hybrid O.I.S.+
