Panasonic Lumix DMC-LX15 User Manual

24
SQW0724
Preparations
Inserting and removing the card (optional)
• Make sure that the camera is turned off.
1
Slide the release lever to the
[OPEN] position and open the
card/battery door
Release lever
2
Insert the card all the way
Do not touch the terminal
• Check the orientation of a card
(terminals face monitor).
• Insert the card all the way firmly until
it clicks.
3
Close the card/battery door
and slide the release lever to
the [LOCK] position
■
To remove card:
Press the centre of
the card.
[OPEN] [LOCK]
●
Keep the Memory Card out of reach of children to prevent swallowing.
●
To remove the card, turn the camera off and wait until the LUMIX indicator on the screen goes
off. (Failure to wait may cause the camera to malfunction and may damage the card or recorded
data.)

Panasonic Lumix DMC-LX15 Specifications

General

Megapixels	20.1 MP
Lens	Leica DC Vario-Summilux
Aperture	f/1.4-2.8
Optical Zoom	3x
Connectivity	Wi-Fi
LCD Screen Resolution	1, 040, 000 dots
Continuous Shooting	10 fps
Built-in Flash	Yes
Battery Life	Approx. 260 shots
ISO Sensitivity	ISO 125-12800 (expandable to 80-25600)
Video Recording	4K UHD 30p, Full HD 60p
Display	3.0-inch TFT LCD
Focal Length	24-72mm (35mm equivalent)
Shutter Speed	60 - 1/4000 sec
Focus Points	49 points
Battery Type	Li-ion Battery Pack (7.2V, 680mAh)
Dimensions	105.5 x 60 x 42 mm
Weight	310 g (with battery and SD card)
Sensor Type	1-inch High Sensitivity MOS Sensor
Image Stabilization	5-axis Hybrid O.I.S.+
