Panasonic Lumix DMC-LX15 User Manual

33
SQW0724
Basics
Buttons/Dials/Levers Used for Recording
Shutter button (Taking pictures)
• Press the [ ] button ( ) to set the drive mode to [ ] ([Single]).
1
Press the shutter button halfway (press lightly) to
focus on the subject
Focus display
( When focus is aligned: illuminated
When focus is not aligned: flashing)
Aperture value
Shutter speed
• The aperture value and shutter speed are displayed. (If the
aperture value and shutter speed are shown in red and flashing,
you do not have the appropriate exposure, unless you are using
the flash.)
2
Press the shutter button fully (push the button all the
way), and take the picture
●
Pictures can be taken only when the image is correctly focused as long as the [Focus/
Release Priority] (→191) is set to [FOCUS].
●
When [Live View Mode] (→200) is set to [ECO 30fps], Digital Zoom is not available.
●
Even during menu operation or picture playback, if you press the shutter button halfway, you can
instantly set the camera ready for recording.
■
Focus range
Focus range is displayed when operating the zoom
Focus range
• The focus range is displayed in red when it is not focused
after pressing the shutter button halfway.
The focus range may change gradually depending on the zoom position.

Panasonic Lumix DMC-LX15 Specifications

General

Megapixels	20.1 MP
Lens	Leica DC Vario-Summilux
Aperture	f/1.4-2.8
Optical Zoom	3x
Connectivity	Wi-Fi
LCD Screen Resolution	1, 040, 000 dots
Continuous Shooting	10 fps
Built-in Flash	Yes
Battery Life	Approx. 260 shots
ISO Sensitivity	ISO 125-12800 (expandable to 80-25600)
Video Recording	4K UHD 30p, Full HD 60p
Display	3.0-inch TFT LCD
Focal Length	24-72mm (35mm equivalent)
Shutter Speed	60 - 1/4000 sec
Focus Points	49 points
Battery Type	Li-ion Battery Pack (7.2V, 680mAh)
Dimensions	105.5 x 60 x 42 mm
Weight	310 g (with battery and SD card)
Sensor Type	1-inch High Sensitivity MOS Sensor
Image Stabilization	5-axis Hybrid O.I.S.+
