Panasonic Lumix DMC-LX15 User Manual

279
SQW0724
Connecting with other devices
Printing
You can connect directly to a PictBridge-compatible printer for printing.
Preparations
• Adjust the print quality or other settings on your printer, as needed.
• Turn on the camera and printer.
1
Connect camera to printer
• Check the plug direction and insert it straight in. (If the cable is inserted in the wrong direction,
the plug could become deformed and cause faulty operation.) Also, do not insert into the wrong
socket. Doing so may cause damage to this unit.
• Do not use any other USB connection cables except the supplied one. Using cables other than
the above may cause a malfunction.
[ ]
• Do not disconnect the USB connection cable (supplied) when the cable disconnection icon
[
] is displayed (may not be displayed with some printers).
[USB/CHARGE] socket
USB connection cable (supplied)
2
Use to select [PictBridge(PTP)] and press [MENU/SET]
3
Use to select a picture and press [MENU/SET]
4
Use to select [Print start] and press [MENU/SET]
(Print settings (→281))

Panasonic Lumix DMC-LX15 Specifications

General

Megapixels	20.1 MP
Lens	Leica DC Vario-Summilux
Aperture	f/1.4-2.8
Optical Zoom	3x
Connectivity	Wi-Fi
LCD Screen Resolution	1, 040, 000 dots
Continuous Shooting	10 fps
Built-in Flash	Yes
Battery Life	Approx. 260 shots
ISO Sensitivity	ISO 125-12800 (expandable to 80-25600)
Video Recording	4K UHD 30p, Full HD 60p
Display	3.0-inch TFT LCD
Focal Length	24-72mm (35mm equivalent)
Shutter Speed	60 - 1/4000 sec
Focus Points	49 points
Battery Type	Li-ion Battery Pack (7.2V, 680mAh)
Dimensions	105.5 x 60 x 42 mm
Weight	310 g (with battery and SD card)
Sensor Type	1-inch High Sensitivity MOS Sensor
Image Stabilization	5-axis Hybrid O.I.S.+
