Panasonic Lumix DMC-LX15 User Manual

38
SQW0724
Basics
Buttons/Dials/Levers Used for Recording
■
Using the level gauge
If you want to make sure that the camera is not slanted or tilted, for example, when you
take a picture of a landscape, use the level gauge indication as a reference.
The yellow line indicates the current angle. Correct the angle of the camera so that it
matches the white line.
Tilting up or down
• In this case, it is facing upward.
Tilting left or right
• In this case, the right side has
dropped.
• When the camera is tilted very little or not at all, the level gauge will turn green.
●
Even when angle is more or less corrected, there may be an error of about ±1 degree.
●
The level gauge may not be displayed correctly or the direction detect function (→30) may not
operate correctly if the pictures are taken with the camera pointing sharply up or down.
During playback
With information
Detailed information
display Histogram display
Without information
([Highlight])
*
100-0001
10:00 1.DEC.2016
100-00011/98
R
G
B
Y
Without information
*
This screen is displayed only when [Highlight] (→194) in the [Custom] menu is set to [ON].
●
Some screens cannot be displayed during playback of certain files, for example motion picture
and 4K burst files.

Panasonic Lumix DMC-LX15 Specifications

General

Megapixels	20.1 MP
Lens	Leica DC Vario-Summilux
Aperture	f/1.4-2.8
Optical Zoom	3x
Connectivity	Wi-Fi
LCD Screen Resolution	1, 040, 000 dots
Continuous Shooting	10 fps
Built-in Flash	Yes
Battery Life	Approx. 260 shots
ISO Sensitivity	ISO 125-12800 (expandable to 80-25600)
Video Recording	4K UHD 30p, Full HD 60p
Display	3.0-inch TFT LCD
Focal Length	24-72mm (35mm equivalent)
Shutter Speed	60 - 1/4000 sec
Focus Points	49 points
Battery Type	Li-ion Battery Pack (7.2V, 680mAh)
Dimensions	105.5 x 60 x 42 mm
Weight	310 g (with battery and SD card)
Sensor Type	1-inch High Sensitivity MOS Sensor
Image Stabilization	5-axis Hybrid O.I.S.+
