Panasonic Lumix DMC-LX15 User Manual

97
SQW0724
Focus, Brightness (Exposure) and Colour tone Settings
Taking pictures with Auto Focus
■
When selecting [ ]
You can enlarge the screen to perform more precise settings of the focus position.
• You cannot set the focus position at the edges of the screen.
→ [Rec] / [Motion Picture] → [AF Mode]
Select [ ] and press
Use to set the focus position and press
[MENU/SET]
• The enlarged assist screen will appear for setting the focus
position.
Move [+] to the focus position
Operation Touch operation Description
Touch Moves [+].
— Pinch in / Pinch out Enlarges/reduces the AF area in small steps.
— Enlarges/reduces the AF area in large steps.
—
Switches the enlarged display. (windowed/full
screen)
[DISP.] [Reset] Resets [+] back to the centre.
• The image of a part of the screen can be enlarged or reduced approximately 3 to 6 times. The
image of the entire screen can be enlarged or reduced approximately 3 to 10 times.
• On the assist screen, it is also possible to record a picture by touching [
].

Panasonic Lumix DMC-LX15 Specifications

General

Megapixels	20.1 MP
Lens	Leica DC Vario-Summilux
Aperture	f/1.4-2.8
Optical Zoom	3x
Connectivity	Wi-Fi
LCD Screen Resolution	1, 040, 000 dots
Continuous Shooting	10 fps
Built-in Flash	Yes
Battery Life	Approx. 260 shots
ISO Sensitivity	ISO 125-12800 (expandable to 80-25600)
Video Recording	4K UHD 30p, Full HD 60p
Display	3.0-inch TFT LCD
Focal Length	24-72mm (35mm equivalent)
Shutter Speed	60 - 1/4000 sec
Focus Points	49 points
Battery Type	Li-ion Battery Pack (7.2V, 680mAh)
Dimensions	105.5 x 60 x 42 mm
Weight	310 g (with battery and SD card)
Sensor Type	1-inch High Sensitivity MOS Sensor
Image Stabilization	5-axis Hybrid O.I.S.+
