Panasonic Lumix S1H Handbook

RAW Data Output
33
Ver. 2.1
Connect the camera and the external recorder with an HDMI cable, and turn them on.
• Use a “High Speed HDMI cable” that has the HDMI logo on it, and that is described as "4K compatible".
1
2
[ ] > [ ] >
[ HDMI RAW Data Output ] > [ ON ]
[ ] > [ ] > [ Rec Quality ]
3
► PAGE 101 : Rec Qualities
Note
• [ Info Display ] is not available. You can not output the camera information display to an external recorder.
• [ Down Convert ] is not available.
• Images equivalent to V-Log recording are displayed on the camera display.
• Only the [ LUT View Assist (Monitor) ] that applies the preset “Vlog_709” can be used.
• When using the [ LUT View Assist (Monitor) ], “709” will be displayed on the screen.
With firmware version 2.1, 12-bit RAW video
data with a maximum resolution of 5.9K can
be output via HDMI to an external recorder.
Compatible External Recorder (As of July 2020)
ATOMOS Ninja V
4K HDR Monitor-Recorder
AtomosOS 10.52 or higher
• Please contact ATOMOS for more information.
3. HDMI Output and TC IN/OUT

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
