Panasonic Lumix S1H Handbook

 Attach the XLR microphone to record audio with high-grade stereo sound quality.
 Equipped with an external switch.
 Record lip-synced audio and video.
 Compatible with 4K video recording with High Resolution Audio (96kHz/24bit) (MOV only).
 Microphones that require phantom power can be used.
* The DMW-XLR1 cannot be used together with built-in microphone or φ3.5mm external microphone.
4
11
12 139
8
14
3 5
2
1 6
7
10
46
4. Audio Settings
XLR Microphone Adaptor DMW-XLR1 * Sold separately
1
INPUT1
LINE/MIC/+48V Switch
2 GAIN Switch
3 LOW CUT Switch
4 AUDIO LEVEL Dial
5
INPUT2
GAIN Switch
6 LOW CUT Switch
7
LINE/MIC/+48V Switch
8 AUDIO LEVEL Dial
9ALC Switch
10 CH1/2 Switch
11 Cable Holder
12 XLR Terminal (INPUT1)
13 XLR Terminal (INPUT2)
14 Cable Holder

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
